Model & type

Weichai WD10G190E214; water-cooled, in-line, 4-stroke direct injection

Horsepower

135/180/1900 kW/HP/rpm

Number of cylinders

6–126 x 130 mm (bore x stroke)

Piston displacement

9.726 L

Min. fuel consumption

235 g/kW·h

Maximum torque

900 N·m@1400-1600 rpm

Torque converter

3-element, 1 stage, 1 phase

Transmission

Planetary gear type, power-shift, forced lubrication

Main drive

Spiral bevel gear, single-stage speed reduction, splash lubrication

Steering clutch

Wet, multi-disc, spring loaded, hand hydraulically separated, inter-linking with steering brake

Steering brake

Wet, floating band structure, foot brake with hydraulic booster

Final drive

2-stage speed reduction of spur gear, splash lubrication

Pitch

203.2 mm

Maximum pressure

14 MPa

Pump type

Gear pump

Discharge

243 L/min

Bore of working cylinder × no.

110 mm × 2

Blade type

Semi-U-blade

Dozing capacity

4.6 m³

Efficiency (Theoretical value 40 m)

250 m³/h

Blade width

3400 mm

Blade height

1300 mm

Maximum drop below ground

540 mm

Maximum lifting height

1095 mm

Maximum tilt adjustment

400 mm
